This machine is a heavy-duty hydraulic straightening & cutting machine specially designed for solid plain round bars ranging from 16 mm to 30 mm in diameter. It adopts split high-power VFD drive configuration: a 75 kW main straightening motor, a 15 kW VFD feeding motor and a 7.5 kW hydraulic cutting motor, with a stable feeding speed of approx. 20 m/min. Its cutting length ranges from 200 mm to 7000 mm with customizable sizing, cutting tolerance is ±0.20 mm and finished bar straightness is within ≤0.15 mm/m. Equipped with ZQ400 reducer and a Ø230×2500 mm straightening drum fitted with 70×70 mm ductile iron wear-resistant straightening inserts, the hydraulic unit uses a heavy cylinder with 300 mm outer diameter which can cut max Ø30 mm 40Cr heat-treated round bar (acceptance standard: raw material hardness HB269). The machine is fitted with three sets of horizontal straightening rollers plus two groups of multi-groove feeding rollers, matched with GB standard UCP320 pillow block bearings; an optional lubrication oil box can be installed below feeding rollers for incoming bar lubrication. Three sets of standard cutting blades are included, and custom blades can be manufactured according to customers’ drawings. Supported by three sets of synchronized powered feeding rollers for stable material conveying, the machine automatically completes feeding, rough straightening, precision straightening and fixed-length hydraulic cutting in one continuous operation. It is widely used for blanking round steel in heavy industries including engineering machinery parts, heavy fasteners and steel structure manufacturing.

This machine is a VFD-type Steel Bar Straightening & Cutting Machine specially for 6.0–16 mm plain round bars. Equipped with multi-wheel precision straightening structure and 3 sets of synchronized powered feeding rollers, it realizes continuous processing including wire pay-off, rough straightening, precision straightening and hydraulic fixed-length cutting in one single pass. Fitted with Inovance VFD control system, separate driving motors are configured for straightening, feeding and cutting to ensure stable adjustable running speed. Its cutting length ranges from 50 mm to 2500 mm with customizable extended length, cutting tolerance reaches ±0.1 mm and finished bar straightness is controlled within ≤0.15 mm/m. Key configurations include GB-standard UCP214 pillow block bearings, JZQ250 reducer and a straightening drum with 7 wear-resistant straightening inserts inside. A cover-open emergency stop safety device is equipped, and cutting blades are available for custom production per client specifications. With robust compact layout and easy operation, it is widely used for precision blanking of round steel in construction stirrup, wire mesh and hardware fastener manufacturing industries.

This Steel Wire Straightening and Cutting Machine is specially developed for processing plain round bars and deformed rebars, which can complete feeding, straightening and fixed-length cutting in one continuous process for coiled steel wires ranging from 3.0 mm to 8 mm in diameter. It adopts separate dual-motor configuration: a 4 kW feeding & straightening motor ensures steady wire feeding, while a 3 kW hydraulic motor powers the cutting unit. The cutting length ranges from 50 mm to 2000 mm, and extended working length can be customized per clients’ demands. The cutting precision reaches ±0.2 mm; feeding speed will automatically decrease when cutting short blanks to guarantee dimensional accuracy. Featuring an integrated compact robust cabinet structure, the machine is easy to operate and widely used in construction stirrup production, wire mesh fabrication and hardware processing industries, ideal equipment for precision cutting of coiled steel.

Model HB-560 is a high-speed intelligent CNC double-column horizontal band saw built with rigid gantry double-column frame for outstanding vibration resistance, designed for high-efficiency precision metal cutting, with max cutting capacity of Φ560 mm round stock and 560×560 mm square stock. Equipped with intelligent CNC control system and touch screen panel, it supports preset cutting length & cutting quantity to realize fully-automatic feeding, clamping, cutting and piece counting in one cycle. The machine features multi-grade adjustable cutting speed and hydraulically infinitely variable saw frame feed speed. Cemented carbide guide inserts prevent saw band deflection, while circulating coolant cooling system continuously lubricates blades to extend saw service life. Fitted with automatic hydraulic clamping vice for stable workpiece fixing, it works perfectly for carbon steel, alloy steel, tool steel, stainless steel and forged profiles. Featuring stable cutting precision and high automation, it is widely used in precision mold processing, auto parts production, steel structure and forging industry for mass raw material blanking.

Model H520 is a gantry double-column CNC horizontal metal band saw with high-rigidity column frame for excellent anti-vibration performance. Its maximum cutting capacity is Φ520 mm for round stock and 520×520 mm for square stock, suitable for cutting round steel, square billet, alloy steel, tool steel and forged workpieces. It is equipped with five fixed cutting speeds: 20, 32, 48, 65, 80 m/min. The saw frame features hydraulically infinitely variable feed speed; the guide arm is manually adjustable and the saw blade adopts manual tensioning design, matched with recirculating coolant cooling system. Cemented carbide guide inserts effectively restrain blade deflection to extend service life of saw band. Power configuration: 5.5 kW main motor, 1.5 kW hydraulic pump motor and 90 W coolant pump motor; hydraulic working pressure ranges 2.5~3 MPa, with an 80 L coolant tank and 50 L hydraulic oil tank, net machine weight is 3 t. The built-in CNC control system enables automatic fixed-length feeding & automatic cutting for mass production. Widely used for batch blanking in steel structure, forging, machinery mold and hardware processing industries.

Model GW4250 is a double-column gantry horizontal metal band saw featuring rigid column design for excellent vibration resistance. Its maximum cutting capacity reaches Φ500 mm for round stock and 500×700 mm for square stock, suitable for cutting large-size round steel, square billet, metal profiles and casting blanks. It is designed with five fixed cutting speeds: 20, 32, 48, 65, 80 m/min, while saw frame feeding adopts hydraulically infinitely variable speed control. The guide arm is manually adjustable and saw blade tension is manually operated, paired with recirculating coolant cooling system for blade temperature control. Cemented carbide guide inserts prevent saw band deviation during cutting. Equipped with a 4.0 kW main motor, 1.5 kW hydraulic pump motor and 90 W coolant pump motor, the hydraulic system works at 3 MPa, with 80 L coolant tank and 50 L hydraulic oil tank. Robust construction ensures stable long-term operation, widely used for raw material blanking in steel structure, tool steel processing, forging and general machinery manufacturing fields.
